Black Resin

Polymer

Precision 3D Printing Material for High-Detail Prototypes

Get a Quote
R
about the material

Specifications

Black Resin, used in Stereolithography (SLA) 3D printing, offers exceptional dimensional stability and smooth surface finishes. It is well-suited for creating high-detail prototypes and functional parts, particularly in high humidity environments.

Key Characteristics:

  • Technology: SLA (Stereolithography)
  • Color: Black
  • Tolerance: ±0.2mm or within 0.3%
  • Recommended Wall Thickness: > 0.8mm
  • Maximum Build Size: 580mm x 580mm x 380mm
  • Heat Deflection Temperature: 46°C
  • Strengths: Smooth surface finish, excellent dimensional stability, suitable for high-precision products, ideal for high humidity environments.
  • Weaknesses: Not suitable for outdoor use, high temperatures, or exposure to sunlight and UV light.

Material Properties

Measurement Test Method Value
Hardness, Shore D ASTM D 2240 79
Flexural modulus, Mpa ASTM D 638M 2,178 – 2,222
Flexural strength, Mpa ASTM D 790M 66.8-67.8
Tensile modulus, MPa ASTM D 638 2,370 – 2,650
Elongation at break ASTM D 638 6-9%
Poisson`s Ratio ASTM D 638 0.41
Impact strength notched Izod ASTM D 256 23-29 kJ/m2
Heat deflection temperature, ℃ ASTMD648@66PSI 46℃
